128-9351
3 of 16
Page 3
PATENTED: www.voxxintl.com/company/patents
6 Pin Power Harness:
1124317
1 Blue Ignition 1 (+)
2 Red/White Battery 1 - 12V (+)
3 Green Ignition 2 (+)
4 Purple Accessory (+)
5 Red Battery 2 - 12V (+)
6 Yellow Starter Output
12 Pin Input/Output Harness:
1124321
1 Green/Orange Tachometer Input
2 Empty Cavity NA
3 Black/Blue Pulse Before Start
4 Black/LT. Green Pulse After Start
5 LT. Blue Ground While Running Output
6 DK. Blue (-) Trunk Release Output
7 Green/Yellow Glow Plug Input
8 Brown (+) Stop Input (Brake Sw.)
9 Gray (-) Negative Stop Input (Hood Sw.)
10 Black/Red Pulse After Shutdown
11 Black/Yellow Pulse During Crank
12 Black/White (-) Horn Output
4 Pin Main Harness:
1124320
1 Black Ground
2 White/Red Parking Light Relay Input
3 Yello/Black To Controlling Alarm’s Ign. Input
4 White Parking Light Relay Output
2 Pin Door Unlock Connector:
1122242
1 Red (-) Door Lock Output
2 Green (-) Door Unlock Output
To Next Page
