Coaxial connection
1� Use a coaxial cable to connect the device by Coaxial jack�
2� Plug the POWER cord and switch it on from the rear panel�
3� Press to turn the power on�
Video-OUT connection
•VGA-OUT
1� Use a VGA cable to connect the device by VGA OUT jack� Connect an earphone cable
with the Audio-OUT�
2� Plug the POWER cord and switch it on from the rear panel�
3� Press to turn the power on�
•VGA-OUT can output the image in the internal computer only�
