Pride Q6 Edge - ELECTRICAL COMPONENTS AND HARNESSES

Q-LOGIC
JOYSTICK
LEFT
MOTOR
NE OR NE+
JOYSTICK
CHARGER
BUS CABLE
EXTENSION
REAR BATTERY
HARNESS
REAR
BATTERY
FRONT
BATTERY
FRONT BATTERY
HARNESS
CHARGER
POWER CORD
BATTERY
CABLE
CIRCUIT BREAKER
RIGHT
MOTOR
POWER
MODULE
14-PIN
RUN PLUG
POWER
TAKE OFF/
INHIBIT
HARNESS
RUN
PLUG
BUS CABLE
MULTIPLIER BOX/HARNESS
OR
OR
ELECTRICAL
COMPONENTS
AND
HARNESSES
3
WARNING! Make note of the
location of any wire ties
that are cut or removed dur-
ing the troubleshooting pro-
cess. Replace these wire
ties once troubleshooting is
complete!
