Structure
The structure of the unit, both the hydronic and the electrical part, is partly customer-specific and
is determined during the purchasing process. These customer-specific features may differ in detail
from the images shown in this chapter.
Structure - hydronic part
In essence, the structure of the unit can be divided into the groups that are explained in this chapter.
The table gives an overview of the variants with references to the associated images and dimension
tables.
Explanation of the table
Use the table to find the correct image, technical drawing and dimension table for a variant
of the NutriJet.
The basic variants (without post-filtration, without pre-mixing) of the NutriJet Inline are in
row 1, the other variants of the NutriJet Inline are in rows 2 and 3.
The NutriJet Bypass is in row 4.
NutriJet variants in main groups
Technical drawing
and dimension
table
DiagramPre-mixingPost-filtrationNumber of
mixing
chambers
Inline /
Bypass
Max. dosage
capacity (l/h)
Technical
specifications -
mechanical (page 47)
NutriJet 100/300/600
Inline (page 12)
--1 or 2Inline100, 300, 600
Technical
specifications -
mechanical (page 47)
NutriJet 100/300
Inline, with
post-filtration and/or
pre-mixing (page 12)
√√1 or 2Inline100, 300
-√
√-
Technical
specifications -
mechanical (page 47)
NutriJet 600 Inline, 1
mixing chamber,
with post-filtration
and/or pre-mixing
(page 12)
√√1Inline600
-√
√-
Technical
specifications -
mechanical (page 47)
NutriJet 600 Inline, 2
mixing chambers,
with post-filtration
and/or pre-mixing
(page 12)
√√2
-√
√-
Technical
specifications -
mechanical (page 47)
NutriJet 300/600
Bypass (page 13)
--1 or 2Bypass300, 600
Legend for the following 5 images
EC sensorsHcabinetA
holder for pH sensorsIdosing channelsB
extra frame with adjustable legs (optional)Jmixing chamberC
EC sensor for EC pre-control (optional)Kframe with adjustable legsD
pre-mix valve (optional)Lsystem pumpE
connection for drain line filter (optional)Mconnection for supply lineF
filter for post-filtration (optional)Nconnection for main irrigation line (line to crop)G
11NutriJet - user - 00.002
Product description
