2
. Connect the included short jumper wire (B) to the wire on
the receiver (C). Connect the other end of the short jumper
wire to the CHEST PULSE jack on the back of the console
(D).
3. Peel the paper off the pad on the bottom of the receiver
(C). Turn the receiver so the cylinder is on the side
shown, and press the receiver into the bottom of the con-
sole base (A) in the indicated location.
Make sure that no wires are pinched. See step 1.
Reattach the console with the screws.
Important: If the
screws are not put back into the same holes from
which they were removed, the console will be dam-
aged.
C
Cylinder
3
A
2
D
B
C
CHEST
PULSE
Jack
10
