9
9. Make sure that all parts are properly tightened before you use the treadmill. Note: Extra hardware may
be included. Keep the included hex keys in a secure place; the large hex key is used to adjust the walking belt
(see page 20). To protect the floor or carpet, place a mat under the treadmill.
8. Attach the Storage Latch (29) and the Latch Spacer (44)
to the left Upright (69) with two 3/4” Screws (2) as shown.
Do not overtighten the Screws.
2
69
29
44
42
36
4
7
7. Press the Upright Wire (42) into the slot in the underside
of the Console Base (47) in the indicated area. Cover the
U
pright Wire with the Right Grip Plate (36). B
e careful
not to pinch the Upright Wire. Tighten three 3/4”
S
crews (2) into the Right Grip Plate and the Console
Base.
2
S
lot
7
8
1. Make sure that the power cord is unplugged. Remove
the indicated screws from the console base (A).
Important: The screws may be different lengths. Keep
track of which screws were removed from which holes.
If you purchase the optional chest pulse sensor (see page 12), follow the steps below to install the re-
ceiver included with the chest pulse sensor.
A
Screws
1
