8
Small
Hole
71
4. Hold the Console Base (47) near the Left Handrail (71).
Attach the ends of the ground wires on the Console Base
t
o the indicated small hole in the Left Handrail with the
Silver Ground Screw (75).
47
75
G
round
W
ires
42
5. Touch the Right Handrail (72) to discharge any static.
Slide the sleeve off the connector on the end of the
Upright Wire (42) as shown in the inset drawing. Next,
press the end of the Upright Wire into the socket in the bot-
tom of the Console Base (47).
The connector should
slide easily into the socket and snap into place.
If the
connector does not slide easily and snap into place, turn
the connector and then insert it. Then, slide the sleeve
back over the connector.
72
47
4
5
47
6. Set the Console Base (47) on the Right Handrail (72) and
the Left Handrail (71).
Attach the Console Base with four
3/4” Screws (2).
Start all four Screws before tightening
them; do not overtighten the Screws.
See the lower drawing. Make sure that the Upright
Wire (42) is routed below the two indicated round
posts (A). Next, press the Upright Wire into the slot be-
tween the square post (B) and the Console Base (47).
2
2
72
71
6
42
Sleeve
Connector
A
B
47
42
To Next Page
