9
4. Hold the Right Upright (85) against the Base
(95). Be careful not to pinch the Upright
Wire (87). Insert two 3/8" x 4" Screws (7) with
two 3/8" Star Washers (11) and a 3/8" x 1 1/2"
Screw (14) with a 3/8" Star Washer (11) into the
Right Upright.
Partially tighten the 3/8" x 4" Screws (7) until
the heads of the Screws touch the Right Upright
(85); do not fully tighten the Screws yet. Then,
partially tighten the 3/8" x 1 1/2" Screw (14).
95
85
87
11
11
14
7
4
5. With the help of a second person, lower the
treadmill so that the Base (95) is flat on the floor.
Attach a Wheel (96) to the Base (95) with a 3/8"
x 2" Bolt (8) and a 3/8" Nut (10). Do not over-
tighten the Nut; the Wheel must turn freely.
Press a Base Cap (89) into the Base (95).
5
8
95
10
89
96
