Pro-Form 500 SPX - Console Wiring and Reed Switch Setup

11
9
58
7
9. Slide the Console (58) onto the Console
Bracket (10) on the Handlebar (7).
10
10. Hold the wire (E) on the Reed Switch (59) on the
left side of the exercise bike as shown.
Connect the wire (E) on the Reed Switch (59) to
the wire (F) on the Console (58).
F
59
E
10
58
