Pro-Form CARBON T10 User Manual

6
PART IDENTIFICATION CHART
Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw-
ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key
number is the quantity used for assembly. Note: If a part is not in the hardware kit, check to see whether it is
preattached. Extra parts may be included.
#10 x 3/4"
Screw (6)–4
3/8" Star
Washer (11)–8
5/16" Star
Washer (12)–10
#8 x 1/2" Ground
Screw (9)–1
#8 x 1/2"
Screw (5)–8
5/16" x 2 1/4" Screw (7)–4
3/8" x 2 3/8" Screw (3)–4
3/8" x 1 3/4" Screw (2)–2
3/8" x 1 1/4"
Screw (1)–2
#8 x 3/4"
Screw (4)–8
1/4" Star
Washer (10)–8

Pro-Form CARBON T10 Specifications

General

Display	10" Smart HD Touchscreen
Speed	0-12 MPH
Weight Capacity	300 lbs
Heart Rate Monitoring	EKG Grip Pulse
Running Area	20" x 55"
Cooling Fan	Yes
Incline	0-12%
Belt	20" x 55"
Folding	SpaceSaver Design with EasyLift Assist
Connectivity	Bluetooth
Programs	iFIT Based
Audio	Dual 2" Speakers
Motor	2.75 CHP Mach Z™ Motor
