8
4
6
34
35
4. Orient the Adjustment Lever (6) as shown.
Attach the Adjustment Lever (6) to the Brake
Axle (37) with two M6 x 16mm Screws (33),
two M6 Split Washers (34), and two M6
Washers (35).
33
37
5
5. Attach the Seat Frame (9) to the Seat Carriage
(7) with four M8 x 40mm Screws (28); start all
the Screws, and then tighten them.
28
9
7
