6
1.
While a second person lifts the rear of the
F
rame (1), attach the Rear Stabilizer (70) to the
Frame with two M10 x 95mm Patch Screws
(82).
2. Orient the Front Stabilizer (73) so that the
Wheels (50) are oriented as shown.
While a second person lifts the front of the
Frame (1), attach the Front Stabilizer (73) to
the Frame with two M10 x 95mm Patch Screws
(82).
70
82
1
1
2
To make assembly easier, read the
information on page 5 before you begin.
73
82
50
50
1
