8619470 145A MULTI-PROCESS MIG-ARC-TIG WELDER V1.0
2 For technical questions call 1-800-665-8685
Specifications
SPECIFICATIONS
Input Voltage 115/230V AC
Input Current Rating 115V 16 to 21A
230V 16 to 27A
Phase Single
Output Current Range
10 to 145A
MIG (GMAW/FCAW) Welding Output @ 25% duty cycle 115V 30 to 80A
230V 30 to 145A
MIG Welding Voltage Range 15-1/2 to 21-1/2A
STICK (SMAW) Welding Output @ 25% duty cycle 115V 10 to 80A
230V 10 to 145A
TIG (GTAW) Welding Output @ 25% duty cycle
115V
10 to 80A
230V 10 to 145A
No-Load Voltage 53V
Welding Capacity 1/4 in.
Wire Feed Speed 60 to 630 in. per minute.
Welding Wire Diameter (MIG-ARC-TIG) 0.025/0.030/0.035 in.
Protection Class
IP21S
Compliance CAN/CSA
INTRODUCTION
The Pro.Point 145A Multi-Process MIG-ARC-TIG Welder incorporates the latest in IGBT technology
for maximum efficiency and longer duty cycles. The welding machine will provide 145 amps of MIG,
ARC and TIG output with dual voltage (115/230V). Settings are displayed on the digital LCD.
Choose manual or automatic control. Select the wire gauge and ARC/MIG/TIG with the
patented Smart-Set operation. The unit automatically adjusts the settings for optional welding.
For MIG/MAG welding, the user can choose gas or gasless options.
The welding unit has a Tweco euro style MIG Torch connection and the machine comes standard
with a Tweco 2 style torch. Inside are wire feeders with steel guide rollers for use with welding
wire. The unit includes both a hot start feature to boost electric arc ignition and an anti-stick
feature that cuts power to prevent overloads when the electrode sticks to the workpiece.
Compatible accessories include the MIG Welding Torch (SKU 8613002), the Multi-System TIG
Torch (SKU 8618456) and the 200A Spool Gun Kit (SKU 8612517).
SAFETY
WARNING! Read and understand all instructions before using this tool. The operator must follow
basic precautions to reduce the risk of personal injury and/or damage to the equipment.
Keep this manual for safety warnings, precautions, operating or inspection and maintenance
instructions.
