WATER BOX WITH AUXILIARY WATER TANK
BLAZER 980073 07/05/03
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 70302 SCR, 5/16-18 X 1” HHCS GR5 PLTD NP
2 00-000072 SCR, 3/8-16 X 2” HXHD
3 70266 SCR, 3/8-16 X 1” HHCS GR5 PLTD DL
4 57006 NUT, 1/4-20 HEX
5 57119 NUT, 3/8-16 HEX NYLOCK
6 87083 WASHER, 5/16 SPLIT LOCK PLTD
7 87171 WASHER, 3/8 FLAT
8 87163 WASHER, 3/8 SPLIT LOCK PLTD
9 02-000143 WASHER, 5/16 FLAT
10 03-000113 CLAMP, HOSE #12 SST
11 03-000246 CLAMP, HOSE #8 SST
12 09-805100 HOSE, WATER 3/4 X 13.5
13 09-805288 HOSE, WATER 5/8 X 27
14 11-800041 ELBOW, STREET 1/2 BR
15 11-800283 RED, 1/2FP X 3/8P BR
16 11-800357 PLUG, 3/4 SOCHD BR
17 11-800401 ELBOW, 3/4 ST BR
18 11-800432 CAP, WATER BOX
19 11-800525 NIP, 3/4 X 2-1/2 BR
20 12-800052 CAP, HOS 3/4 BR
21 12-800095 FTTG, BRB 3/4P X 3/4H BR
22 12-800269 FTTG, BRB 1/2P X 5/8H BR
23 13-806008 DSC, 3/8F X 3/8FP
24 15-808072 VALVE, BALL 3/4FP BS
25 15-808110 VALVE, FLOAT TM
26 19-807014 BALL, FLOAT
27 43-807008 WASHER, HOSE 5/8ID X 1”OD
28 50-500511 PLATE, INSTALL MT
29 50-502092 PLATE, FRT TANK SUPPORT
30 54-501715 FLAT ROD, TM
31 56-502505 ENCL, TANK SUPPORT W/ DEM PUMP
32 58-500899 MLDG, WATER TANK 60G W/ OVRFI
33 64-950681 HARNESS, WATER PUMP NOT SHOWN
34 66-945614 KIT, DEM PUMP FLOJET 60G
