Prochem BLAZER PLUS - Demand Pump

WATER TANK, DUAL WITH DEMAND PUMP
BLAZER 980073 07/05/03
5-50
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
- 66-945260 TANK, DUAL SADDLE W/DMD PUMP COMPLETE
- 66-945265 SINGLE SADDLE TANK W/DMND PMP COMPLETE
1 50-501774 HOLD DOWN, SADDLE TANK GRAY
2 87171 WASHER, 3/8 FLAT
3 87163 WASHER 3/8 SPLIT LOCK
4 00-000072 SCR, 3/8-16 X 2’ HXHD
5 11-800432 CAP, WATER BOX
6 11-800041 ELL, STREET 1/2 BR
7 12-800278 FTTG, BRB 1/2P X 3/4H BR
8 03-000113 CLAMP, HOSE #12 SST
9 09-805456 HOSE, WTR 3/4 X 96”
10 11-800085 TEE, 1/2 BRASS
11 56-502000 ASSY, BASE SADDLE TANK GRAY
12 58-500661 MOLDING, WATER TANK
13 11-800168 PLUG, 1/2 BRASS HXHD
14 50-500511 PLATE, INSTALL MT
15 57119 NUT, 3/8-16 HEX NYLOCK
- 41458 SHLR, CHEM, 10-GAL JUG NOT SHOWN
