WATER PUMP
BLAZER 980073 09/16/02
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 70266 SCR, 3/8-16 X 1” HHCS GR5 PLTD
2 70357 SCR, 1/2-13 X 3 FULL THREADS
3 00-000340 SCR, MACH 5/16-18 X 1” GR8
4 02-000057 FLATWASHER, 1/2 HEAVY
5 87171 WASHER, 3/8 FLAT
6 87163 WASHER, 3/8 SPLIT LOCK
7 05-008039 OIL, AEON PD NOT SHOWN
8 09-805440 TUBING, IMPOLENE X 35”
9 09-805628 TUBING, IMPOL 1/4 X 23
10 41-905024 PUMP, 3LVLTHC
11 44-802204 HUB, P1 X 3/4”
12 44-802212 PULLEY, 2TA54
13 54-500680 KEY, 3/16 SQ X 7/8
14 54-501593 NIP, VAC EXH OUTLET
15 56-501816 BRKT, VAC ADJ
16 61-951142 VALVE, VACUUM RELIEF
17 57114 NUT, 7/16-14 HEX
18 04-000091 SPRING, VAC REL VLV
19 12-500059 CONN, 1/8P X 1/4POLY BR
20 12-800099 ELL, 1/8P X 1/4 POLY BR
21 43-807074 DIAPHRAM, VAC REL VLV
22 56-501615 STEM, VAC REL VLV#4 VAC
23 03-000112 CLAMP, HOSE #48
24 09-805341 HOSE, VAC 2.88 X 25.0 BLK
25 39280 HOSE, 3/8 RUBBER X 8’
