OPERATION
BLAZER 980073 09/16/02
3-14
WASTE PUMP
1. If your unit is equipped with an automatic waste
pump, connect one end of a garden hose to the
pump-out connection on the console and the
other end to an appropriate waste disposal.
2. Turn the pump-out switch on the control panel
to the ON position. The waste pump will operate
automatically throughout the cleaning operation.
We recommend that you use a 3/4" I.D. water hose
as a waste pump outlet hose. DO NOT use a hose
smaller than 5/8" I.D.
NEVER use your automatic waste pump outlet hose
as a water inlet hose.
NEVER dispose of waste in storm drains, water
ways, or on ground areas. Always dispose of
waste in accordance with Local, State, or Federal
law.
OPERATION
Once you have completed steps 1 through 9,
proceed with the cleaning operation. Your unit
should be in the full throttle position when cleaning
or extracting. A float switch located inside the
waste tank will automatically shut down the unit
when it reaches its full capacity. When this occurs,
empty the waste tank before continuing.
CLEANING
Observe the following guidelines, while cleaning:
1. Before proceeding make sure the nozzles are
functioning properly.
a. To check, hold the wand about one foot
above the surface to be cleaned and open
the wand valve. A full spray should be
observed from the cleaning nozzles.
b. If the nozzles are not showing a full spray
pattern, adjust nozzles for proper pattern,
clean, or replace nozzles.
2. Normally, chemical is applied on the push stroke
of the wand when cleaning, and vacuuming is
done on the pull stroke. For heavily soiled
carpets the wand may be used in a scrubbing
manner, applying chemical in both push and pull
strokes. Always finish up an area with a vacuum
pull stroke.
3. When cleaning, keep the working opening
(mouth) flat on the surface being cleaned. Keep
the wand moving when the valve is open.
4. The unit will automatically shut-down when the
waste tank is full. This will prevent water being
drawn into the vacuum pump. If shut-down
occurs, empty the waste tank before proceeding.
NEVER dispose of waste in storm drains,
waterways, or onto the ground. Always dispose
of waste in accordance with Local, State, and
Federal laws.
UPHOLSTERY CLEANING
Upholstery Tool, Part #78513
1. Use one (1) "80015" spray tip in either tool.
2. Fine pressure adjustments should be made at
the tool itself, by using the adjusting knob
located on the valve.
STAIR TOOL CLEANING
Stair Tool, Long, Part #78519
Stair Tool, Short, Part #78521
1. Use one (1) "9502" spray tip in your stair tool.
