Prochem BLAZER PLUS - Vacuum Exhaust Heat Exchanger

VACUUM EXHAUST HEAT EXCHANGER
BLAZER 980073 09/16/02
5-28
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 70270 SCR, 1/4-20 X 3/4 HHCS PLTD
2 70105 SCR, 1/4-20 X 1.75 HHCS PLTD
3 87162 WASHER, 1/4 SPLIT LOCK
4 02-000066 FLATWASHER, 1/4
5 03-000112 CLAMP, HOSE #48
6 03-000149 CLAMP, CABLE 1-1/4 ID 5/16 BLT
7 03-000246 CLAMP, HOSE #8 SST
8 09-805330 HOSE, WTR 5/8 X 53”
9 09-805478 HOSE, VAC 2.88 X 2.5 BLK
10 43-807080 GASKET, VAE HE INLET
11 43-807081 GASKET, VAC HE CORE
12 56-502078 HOUSING, VAC HEAT EXCHANGER
13 57-520082 MUFFLER, VAC BACK
14 58-700027 PAD, VAC HE CORE
15 61-950886 VAC HE CORE
16 09-805234 HOSE, WATER 5/8 X 36”
