OPERATION
BLAZER 980073 09/16/02
3-1
TECHNICAL SPECIFICATIONS
ITEM DIMENSION/CAPACITY
Engine speed 3200 rpm (high speed)
1400 rpm (idle speed)
Water pump rpm 1480 rpm
Vacuum pump rpm 3200 rpm
Water flow rate 3.5 GPM
Water pump pressure 1000 PSI (maximum)
Vacuum relief valve 13” Hg
Waste tank capacity 52 gallons (at shut off)
Console weight 486 lbs.
Console weight (with waste tank & accessories) 670 lbs (1103 lbs. If waste tank is full)
TORQUE VALUES
Engine hub 264 inch lbs 22 foot/lbs
Vacuum pump hub 192 inch/lbs 16 foot/lbs
JET SIZING:
Prochem recommends floor tool tip sizing not exceed a total of “.04”. Using larger jet sizes on your BLAZER
PLUS may reduce cleaning temperatures.
Example: Dual jet wand uses two 11002 jets. (110° spray angle w/ 02 orifice)
02 x 2 = 04
Upholstery tool jet size: 80015 Stair tool jet size: 9502
