FRONT PANEL
BLAZER 980073 09/16/02
5-2
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 19-800075 CUP, OIL FILL 1/8P
2 15-808081 REG, PRES W/O INNER SPRING
3 22015 COUPLER, 1/4 QD
4 15-808022 VALVE, 3-WAY BALL 1/8FP
5 50-501851 HOOD, BLAZER
6 00-000400 SCR, 1/4-20 X 1/2” THRUSHD PHIL
7 58-700023 PAD, 1/4 TURN VIBR
8 18-808513 FLOWMETER 1/8FP
9 15-808106 VALVE, METER 1/8FP
10 34-903000 HOURMETER
11 18-808526 GAUGE, WATER PRESSURE
12 18-808525 GAUGE, VACUUM 30” HG
13 00-000337 SCR, 10-32 X 1” SPCHD SST
14 57030 NUT, 10-32 HEX NYLOCK
15 33-900168 BOARD, TERMINAL
16 31-900172 JUMPER, TERM BOARD
17 33-900161 BREAKER, CIRC 30A
18 49-802518 CABLE, CHOKE
19 33-900163 BREAKER, CIRC 20A
20 49-802505 CABLE, THROTTLE
21 32-900174 KEYSWITCH
22 32-900087 SWITCH, TOGGLE
23 56-502074 MT, CONTR PNL BLZR, EXP
24 13-806008 DXC, 3/8F X 3/8FP
25 56-500522 NIP, WATER INLET
26 00-000210 SCR, 1/4-20 X 3/4 SOCHD
27 87162 WASHER, 1/4 SPLIT LOCK
28 56-502120 ASSY, LWR FR PNL BLZR
- 48-941197 DECAL, CONDENSED INTRUCT NOT SHOWN
- 48-941195 DECAL, HOOD PROCHEM TM NOT SHOWN
- 48-941212 DECAL, WARN & INTRUCT NOT SHOWN
- 48-941391 DECAL, PNL BLZR NOT SHOWN
