Prochem BLAZER PLUS - Page 64

BYPASS MANIFOLD
BLAZER 980073 09/16/02
5-20
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 70270 SCR, 1/4-20 X 3/4 HHCS PLTD
2 00-000132 SCR, 1/4-20 X 1-1/2 HXHD
3 87162 WASHER, 1/4 SPLIT LOCK
4 02-000066 FLATWASHER, 1/4
5 12-800040 ELL, 1/8P X 1/4T BR
6 12-800261 ELL, 1/8P X 1/4T X 45 DEG
7 15-808111 ASSY, BYPASS MANIFOLD
8 56-502254 BRKT, BYPASS MTG
9 14-806552 SCREEN, BYPASS MANIFOLD
10 43-810053 O-RING, .676ID X .816OD
11 52-501659 MANIFOLD, BYPASS
12 52-501665 ORIF. BYPASS MANIFOLD
13 53-501523 CAP, CHK VALVE MANIFOLD STRNR
14 10-805150 HOSE 3/16 X 30”
15 10-805288 HOSE, 3/16 X 17”
16 10-805372 HOSE, 3/16 X 21-3/4
