WASTE TANK
BLAZER 980073 09/16/02
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 00-000078 SCR, 1/4-20 X 1” HXHD GRD8
2 00-000167 SCR, 1/4-20 X 6” HXHD
3 67006 RIVET, 3/16 OD X 5/8 AL
4 57006 NUT, 1/4-20 HEX
5 87162 WASHER, 1/4 SPLIT LOCK
6 02-000066 FLATWASHER, 1/4
7 03-000242 CLAMP, CABLE 3/4ID 1/4BLT
8 31016 ELBOW, 1/4NPT STREET
9 11-800402 PLUG, 1-1/4 HXHD PVC
10 12-800092 FTTG, BRB 1/4 X 5/16H BR
11 12-800261 ELL, 1/8P X 1/4T 45 DEG
12 14-806518 STRAINER, WAST TANK 2-1/2”
13 31-900179 COVER, BATTERY TERMINAL
14 36-900056 BATTERY
15 46-802510 LATCH, DRAW 2-7/8 SST
16 47-700007 SHIELD, BAT MT HT
17 50-501697 SPACER, BAT SHLF MTG
18 56-500188 COVER, BATTERY
19 56-501779 TRAY, BATTERY
20 56-501793 STRAINER BOWL
21 56-502235 TANK, WASTE
22 61-950621 ASSY, WST PMP OUT SW KIT
23 61-951174 ASSY, LID WAST TANK
24 33-900194 FLOAT
25 33-900195 SHAFT, FLOAT
26 33-900200 HOUSING, MAGNET
27 33-900201 SUPPORT, PIVOT
28 33-900214 SWITCH, MICRO
29 43-807541 GASKET, WASTE TANK LID
30 48-941297 DECAL, ARROW-WST TNK LID
31 56-501855 LID, WASTE TANK
32 03-000065 CLAMP, HOSE #4 SST
33 09-805040 HOSE, BRD 5/16 X 32
34 03-000054 CLMP, HOSE #32 1.5625/2.5 SST
35 09-805332 HOSE, 2.0 X 120.0 BLK
36 12-800357 FTTG, BARB 1-1/2P X 2H
37 15-808080 VALVE, BALL PVC 1-1/2FP
38 61-951195 ASSY, WATER BOX
