AUTOMATIC PUMPOUT
BLAZER 980073 09/16/02
5-36
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 00-000210 SCR, 1/4-20 X 3/4 SOCHD
2 00-000311 SCR, 1/4-20 X 1/2 SHCS SS
3 00-000312 SCR, CAP 1/4 X 1 SOCHD
4 00-000399 SCR, CAP 1/4 X 1 3/8 SOC
5 00-000241 SCR, CAP 10-32 X 2 SOCHD SS
6 57245 NUT, 1/4-20 HEX NYLOCK SS
7 87162 WASHER, 1/4 SPLIT LOCK
8 87165 WASHER, #10 SPLIT LOCK
9 04-000312 RING, RETAIN EXT 1/2
10 04-000334 BALL, NYL ID
11 04-000335 RING, SNAP 1-7/8D
12 04-000342 SPRING, PUMP-OUT BALL PRESS
13 52-501822 INL, HOSE CONN WST TNK
14 16-808241 DIAPH, WST TNK PMP-OUT
15 40-902151 MOTOR, 1/8HP 12V
16 43-807117 GSKT, CVR TOP PMPOUT
17 43-807118 GSKT, CVR SD PMPOUT
18 43-810091 SEAL, PUMPOUT SHFT
19 43-810100 SEAL PUMPOUT CAM
20 43-810101 O-RING, 800/1000 .072
21 43-807116 GSKT, IN/OUTLT WST TNK-PM
22 45-801927 BRG, SHFT PUMP-OUT
23 49-876301 VENT, UPR SHFT BRNG HSG
24 50-502025 PL, CVR TOP PUMP-OUT
25 50-502026 PL, CVR SD PUMP-OUT
26 00-000311 SCR, 1/4-20 X 1/2 SHCS SS
27 11-800504 GA, FLOW SIGHT 3/8 NPT
28 52-501828 BTM, PLNGR WST TNK PMP-OUT
29 52-501829 SHT, 3/4” STROKE WST TNK
30 52-501914 RD, CONNECT WST PMP-OUT
31 52-501915 GUIDE, PLNGR WST PUMP-OUT
32 52-501921 PIN, WRIST PUMP-OUT
33 52-501934 TOP, PLNGR PUMP-OUT
34 52-501950 BUSH, THREADED
35 52-501822 INL, HOSE CONN WST TNK
36 56-502428 BRKT, PMP-OUT SW/CCT BRKR
37 52-501821 TOP, WST TNK PUMP-OUT
38 52-501820 BASE, WST TNK PMP-OUT
To Next Page
