SHELF ASSEMBLY
BLAZER 980073 07/05/03
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
- 65-950392 VAN STORAGE UNIT
1 56-501921 SHELF, LWR
2 02-000066 FLATWASHER, 1/4
3 87162 WASHER, 1/4 SPLIT LOCK
4 70721 SHOULDER BOLT, 182 OD X 2.25 L
5 70270 SCR, 1/4-20 X 3/4 HHCS PLTD
6 50-501840 BRKT, ADJUST MTG SLOT
7 56-502067 BRKT, ADJUST MTF HLDR
8 56-501942 BRKT, SHELF MOUNTING
9 50-501753 HOLDER, STAIR TOOL
10 01-000105 LOCK NUT, 1/4-20 HXHD
11 56-501922 PANEL, SHLF END
12 50-501749 WASHER, NYLON
13 56-501920 DRAWER, SHELF GRAY
14 46-802506 LATCH, ADJ GRIP
15 50-501755 HOLDER, UP TO HOSE
16 50-501754 HOLDER, UPHST TL
17 48-941152 DECAL, PROCHEM
- 66-945424 KIT, ADJ BRKT.
INCLUDES PARTS 6,7 &
MOUNTING HARDWARE
