HOSE REEL
BLAZER 980073 07/05/03
5-54
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
- 65-950393 HOSE REEL, HIGH PROFILE PC
1 56-501962 REEL, VACUUM HOSE GRAY
2 03-000124 CLAMP, MFLR 1-3/4
3 52-501685 BUSHING, HOSE REEL
4 56-501960 BASE, HOSE RL (250’)
5 56-502207 BRKT, LOCKOUT HOSE REEL
6 61-950854 LATCH ASSEMBLY
7 02-000066 FLATWASHER, 1/4
8 87162 WASHER, 1/4 SLPIT LOCK
9 70270 SCR, 1/4-20 X 3/4 HHCS PLTD
10 57031 NUT, 5/16-18 HEX
11 56-501968 REEL, HP HOSE GRAY
12 45-802138 BEARING HOSE REEL
13 02-000143 FLATWASHER, 5/16
14 87083 WASHER, 5/16 SPLIT LOCK PLTD
15 70302 SCR, 5/16-18 X 1” HHCSGR5PLT
16 44-802122 FLANGE, 47MST
17 56-501961 BODY, HP HOSE GRAY
18 00-000072 SCR, 3/8-16 X 2” HXHD
19 50-500511 PLATE, INSTALL MT
20 87171 WASHER, 3/8 FLAT
21 57119 NUT, 3/8-16 HEX NYLOCK
22 55-501789 PIN, LOCK HOSE REEL
23 50-501812 BRKT, HOSE REEL LOCK
24 04-000302 SPRING, LOCK-LOCK PIN ASSY
25 04-000303 CLIP, RETAINER-LOCK PIN ASSY
