3.3. Protocol selection
The RS485 protocol is set using DIP switch 7.
When the switch is in the ON position the Modbus RTU protocol is selected.
Switch 7 Protocol selection
OFF BACnet MS/TP
ON Modbus RTU
3.4. Deadband mode
The Deadband feature can be enabled using DIP switch 8.
When the switch is in the OFF position the Deadband feature is disabled.
When the switch is in the ON position the Deadband feature is enabled.
Switch 8 Deadband feature
OFF Disabled
ON Enabled
