Holding Register (Analogue Output) Applicable Unit Type
Register Name Addr
Modicon
Address
Details
FTC4 FTC5
CAHV
master
CAHV
slave
CRHV
master
CRHV
slave
QAHV
master
EAHV
master
EAHV
slave
Fault/Error Code (hex)
[READ ONLY]
9 40010
0x8000 = No error
0x6999 = Bad communication with unit
(Refer to indoor unit documentation for description
of other fault code values)
9 9 9 9 9 9
MelcoBEMS MINI (A1M)
Firmware Version
[READ ONLY]
10 40011 MelcoBEMS MINI (A1M) Firmware Version
9 9 9 9 9 9 9 9 9
Modbus Comms Counter
[READ ONLY]
11 40012
Value of a counter which increments upon every
valid Modbus command received. Counter is reset
to zero when value exceeds 65535.
9 9 9 9 9 9 9 9 9
Fault Code (decimal)
[READ ONLY]
12 40013
8000 = No error
6999 = Bad communication between A1M and unit
(Refer to unit documentation for description of other
fault code values)
9 9 9 9 9 9
System Type Detected
[READ ONLY]
13 40014
0 = ATA unit connected
1 = ATW system connected
2 = Lossnay system connected
255 = Undetermined (no unit detected yet)
9 9 9 9 9 9 9 9 9
System On/Off 25 40026
0 = System OFF
1 = System ON
2 = Emergency Run (read only value)
3 = Test Run (read only value)
9 9
9
#14
(9)
#18
9
#14
(9)
#18
9
9
#14
(9)
#18
Operating Mode 26 40027
0 = Stop
1 = Hot Water
2 = Heating
3 = Cooling
4 = No voltage contact input (hot water storage)
5 = Freeze Stat
6 = Legionella
7 = Heating-Eco
8 = Mode 1
9 = Mode 2
10 = Mode 3
11 = No voltage contact input (heating up)
9
#4
(9)
#18
9
#5
(9)
#18
9
9
#13
(9)
#18
Operating Mode (DHW) 27 40028
0 = Normal
1 = Eco
