Holding Register (Analogue Output) Applicable Unit Type
Register Name Addr
Modicon
Address
Details
FTC4 FTC5
CAHV
master
CAHV
slave
CRHV
master
CRHV
slave
QAHV
master
EAHV
master
EAHV
slave
Water Outlet Temperature 2
(signed)
[READ ONLY]
258 40259
Temperature value in ºC multiplied by 100.
(see note *)
9 9
9 9
9 9
Water Outlet Temperature 2
[READ ONLY]
259 40260
Temperature value in ºC multiplied by 100.
(see note **)
9 9
9 9
9 9
Evaporating Temperature 2
(signed)
[READ ONLY]
260 40261
Temperature value in ºC multiplied by 100.
(see note *)
9 9
9 9
9 9
Evaporating Temperature 2
[READ ONLY]
261 40262
Temperature value in ºC multiplied by 100.
(see note **)
9 9
9 9
9 9
Water Pump 1 – PWM Duty
[READ ONLY]
262 40263
Duty value in %
0 = 0% … 100 = 100%
9
Water Pump 1 – PWM Duty
Feedback
[READ ONLY]
263 40264
Duty value in %
0 = 0% … 100 = 100%
3-Way Valve 1
[READ ONLY]
264 40265
0 = OFF (stop)
1 = ON (run)
9
9
Version of Protocol (upper)
[READ ONLY]
265 40266
Version of Protocol is a value in BCD
e.g. V3.01 = 3 (upper) and 1 (lower)
9 9 9 9 9 9 9 9 9
Version of Protocol (lower)
[READ ONLY]
266 40267
Version of Protocol is a value in BCD
e.g. V3.01 = 3 (upper) and 1 (lower)
9 9 9 9 9 9 9 9 9
Version of Model (upper)
[READ ONLY]
267 40268
Version of Model is a value in BCD
e.g. V2.00 = 2 (upper) and 0 (lower)
9 9 9 9 9 9 9 9 9
Version of Model (lower)
[READ ONLY]
268 40269
Version of Model is a value in BCD
e.g. V2.00 = 2 (upper) and 0 (lower)
9 9 9 9 9 9 9 9 9
Capacity of Supplying Electricity
[READ ONLY]
269 40270
Value in Watts
0 = 0,0 W
…
255 = 25,5 W
9 9 9 9 9 9 9 9 9
