Procon A1M - Page 73

71
Discrete Input (Digital Input) Applicable Unit Type
Register Name Addr
Modicon
Address
Details
FTC4 FTC5
CAHV
master
CAHV
slave
CRHV
master
CRHV
slave
QAHV
master
EAHV
master
EAHV
slave
Heat Pump Slave 5 ON/OFF
(address 6 for CAHV/CRHV)
12 10013 0 = Stop, 1 = Run
9 9 9 9
Heat Pump Slave 6 ON/OFF
(address 7 for CAHV/CRHV)
13 10014 0 = Stop, 1 = Run
9 9 9 9
Heat Pump Slave 7 ON/OFF
(address 8 for CAHV/CRHV)
14 10015 0 = Stop, 1 = Run
9 9
Heat Pump Slave 8 ON/OFF
(address 9 for CAHV/CRHV)
15 10016 0 = Stop, 1 = Run
9 9
Boiler ON/OFF
16 10017
0 = Stop, 1 = Run
9 9 9 9
External Heater Operation 1 0 = Stop, 1 = Run
9 9
Booster Heater 1 ON/OFF 17 10018 0 = Stop, 1 = Run
9 9
Booster Heater 2 ON/OFF 18 10019 0 = Stop, 1 = Run
9 9
Booster Heater 2+ ON/OFF 19 10020 0 = Stop, 1 = Run
9 9
Immersion Heater ON/OFF 20 10021 0 = Stop, 1 = Run
9 9
Water Pump 1 ON/OFF 21 10022 0 = Stop, 1 = Run
9 9 9 9 9 9 9 9
Water Pump 2 ON/OFF 22 10023 0 = Stop, 1 = Run
9 9 9
Water Pump 3 ON/OFF 23 10024 0 = Stop, 1 = Run
9 9 9
3-Way Valve ON/OFF 24 10025 0 = Stop, 1 = Run
9 9
2-Way Valve 2 ON/OFF 25 10026 0 = Stop, 1 = Run
9 9
