PRODIS CL20 - Levelling the Ice Maker; Electrical Connection and Specifications; Water Supply and Drain Connection

01. CARE SHOULD BE TAKEN TO ENSURE THE
ICE MAKER IS PERFECTLY LEVEL FOR CORRECT
OPERATION. THE UNIT HAS 4 ADJUSTABLE FEET
ON THE BOTTOM FOR LEVELLING. A SPIRIT
LEVEL SHOULD BE USED TO CHECK THE UNIT IS
PERFECTLY LEVEL, IF THE UNIT IS NOT LEVEL ICE
PRODUCTION WILL BE AFFECTED.
LEVELLING THE ICE MAKER
WARNING
ALL WIRING AND ELECTRICAL CONNECTION
MUST CONFIRM TO NATIONAL REGULATIONS.
ALL ELECTRICAL CONNECTIONS MUST BE
UNDERTAKEN BY A COMPETENT ENGINEER OR A
QUALIFIED ELECTRICIAN.
ELECTRICAL CONNECTION
01. THIS ICE MAKER MUST BE PLUGGED IN
TO AN INDEPENDENT POWER SOURCE OR
AN ELECTRICAL SOCKET OF VOLTAGE AND
FREQUENCY SPECIFIED. ELECTRICAL RATING
INFORMATION CAN BE FOUND ON THE DATA
PLATE OF THE ICE MAKER.
02. THIS ICE MAKER MUST BE CONNECTED TO
AN INDEPENDENT CIRCUIT BREAKER OR FUSE.
03. DUE TO POTENTIAL SAFETY HAZARDS THIS
ICE MAKER IS NOT RECOMMENDED FOR USE
WITH AN EXTENSION LEAD
PART II
ELECTRICAL SPECIFICATION
MODEL VOLTAGE TOTAL POWER CURRENT
CL20 230V/50Hz 155w 0.9 amps
WARNING
IF THE POWER SUPPLY CABLE IS DAMAGED,
DO NOT INSTALL OR OPERATE THE MACHINE
UNTIL THE CABLE HAS BEEN REPLACED BY
AN AUTHORISED SERVICE PARTNER OR A
QUALIFIED ENGINEER.
WARNING
PLEASE TAKE PROTECTIVE MEASURES WHEN
THE AMBIENT TEMPERATURE DROPS BELOW
10°C.
WARNING
ALL ELECTRICAL CONNECTIONS MUST
CONFORM TO LOCAL REGULATIONS AND BE
CARRIED OUT BY A QUALIFIED ENGINEER
WE RECOMMEND INSTALLATION OF AN
INLINE WATER FILTER TO THIS ICE MAKER.
THIS WILL REDUCE LIMESCALE BUILD UP,
IMPROVE EFFICIENCY, AND EXTEND THE
OVERALL LIFESPAN OF THE UNIT. A WATER
FILTER WILL ALSO REMOVE IMPURITIES AND
CREATE A CLEARER, BETTER TASTING ICE CUBE.
01. WATER SUPPLY PRESSURE SHOULD
BE BETWEEN 1.4BAR AND 5.5BAR. IF THE
PRESSURE EXCEEDS 5.5 BAR A PRESSURE
REDUCING VALVE MUST BE USED.
FAULTS DUE TO LOW OR HIGH WATER PRESSURE
ARE NOT COVERED UNDER WARRANTY.
02. THE DRAIN CONNECTION
SHOULD BE INSTALLED INTO AN
OPEN TRAPPED DRAIN. (SEE FIG.1).
03. THE ICE MAKER DRAIN IS GRAVITY FLOW,
THE ICE MAKER NEEDS TO BE INSTALLED ABOVE
THE HEIGHT OF MAIN DRAIN TO ALLOW FOR EASY
DRAINING
WATER SUPPLY AND DRAIN CONNECTION
FIG.1
04. ATTACH ONE END OF THE WATER INLET
HOSE TO THE REAR OF THE MACHINE AND
ATTACH THE OTHER END OF THE HOSE TO THE
MAINS WATER CONNECTION. IT IS ADVISABLE TO
HAVE A STOP VALVE CLOSE TO THE ICE MAKER.
CL200718UM Rev 1.3
3
