DATI TECNICI
TECHNICAL DATA
NEOS
DATI TECNICI Italiano TECHNICAL DATA English
System type
Nominal impedance
Input power rating continuous
Input power rating peak
Frequency response
Sensitivity
Low frequency device
High frequency device
Crossover frequency
Angular coverage
Signal processing
Connectors
Construction
Finishing
Flying system
Trapezoidal taper
Monitor taper
Mounting pole
Dimensions (W x H x D)
Weight
Constant voltage transfomer
System type
Amplifier continuous power
Max SPL
Connectors
Controls
Cooling
Crossover frequency
Input Impedance
Input Sensitivity
Power Supply
Maximum Consumption
Rated Consumption (1/8 Pout)
Signal Processing
Weight
NEOS 122P NEOS152P NEOS115SP
2 way vented enclosure 2-way vented enclosure Passive vented enclosure subwoofer
8 ohm 8 ohm 8 ohm
800 W 1000 W 500 W
1600 W 2000 W 1000 W
40 Hz - 20 kHz 40 Hz - 20 kHz from 40 Hz
100 dB 1 W/1 m 99 dB @ 1 W/1 m 98 dB @ 1 W/1 m
12” neodymium woofer - 3” VC 15'' neodymium woofer - 4" VC 15'' neodymium woofer - 3" VC
1,4” compression driver - titanium diaphrag 2'' compression driver - titanium diaphragm -
1200 Hz 1200 Hz 80 Hz - 160 Hz
100°>80° H x 60° V with asymmetrical rot
a
90°>60° H x 50° V with asymmetrical rotat
a
-
Proel DSO480 (bi-amp mode) Proel DSO480 (Biamp mode) Proel DSO480, Proel ASO25
2 x Neutrik Speakon® NL4MP linked 2 x Neutrik Speakon® NL4MP linked 2 x Neutrik Speakon® NL4MP linked
15-18mm birch plywood with 15 and 18 mm birch plywood 15 and 18 mm birch plywood
Anti-scratch highly resistant blackpaint Anti-scratch highly resistant blackpaint Anti-scratch highly resistant blackpaint
4 x Fly tracks - side and 1 x M10 rear 6 x Fly tracks side and rear 5 x M10 - top, bottom, rear
10° 10° 10°
42° 42° -
1 x bottom double angle flange, 0° or 7.5° 1 x bottom double angle flange, 0° or 7.5° 1 x top
410 x 600 x 360 mm 450 x 770 x 490 mm 500 x 520 x 600 cm
24 Kg (52.9 lb) 33 kg (72.7 lb) 26 kg (57.3 lb)
-
NEOS 122A NEOS152A NEOS115SA
2 way digitally processed active enclosure 2-way digitally processed active enclosure
Active vented subwoofer enclosure
with stereo crossover
750 W + 250 W (limited) bi-amp
1000 W + 500 W (limited) bi-amp
1000 W
132 dB 132 dB 131 dB
IN - LINK: XLR M - XLR F
MAIN LINK: PowerCon (NAC3MPB)
MAIN: PowerOcn (NAC3MPA)
IN - LINK: XLR M - XLR F
MAIN LINK: PowerCon® (NAC3MPB)
MAIN: PowerCon® (NAC3MPA)
IN: 2 x Combo® - LINK: 2 x XLR M - OUT: 2
x XLR M
MAIN: PowerCon® (NAC3MPA)
MAIN LINK: PowerCon®
(
NAC3MPB
)
AMP Level (-18 dB), gnd lift , HPF 80 Hz Amp level (-18 dB), gnd lift, HPF 80 Hz
SUB level, flat out, gnd lift,
x-over freq. selection 100\160 Hz, phase
variabile speed DC fan variabile speed DC fan Natural convection
1200 Hz 1200 Hz 100 Hz or 160 Hz
LINE: 20 kohm balanced, 10 kohm unbalanc LINE: 20 kohm balanced, 10 kohm unbalanc LINE: 20 kohm balanced, 10 kohm unbalanc
LINE: +4 dBu / 1.25 V LINE: +4 dBu / 1.25 V LINE: +4 dBu / 1.25 V
230 VAC 50Hz or 117 VAC 60 Hz 230 VAC 50Hz or 117 VAC 60 Hz 230 VAC 50Hz or 117 VAC 60 Hz
2000 VA 2640 VA 1340 VA
510 VA 670 VA 370 VA
24 bit / 48 kHz 24 bit / 48 kHz -
28 Kg (61.7 lb) 36 kg (79.4 lb) 28 kg (61.7 lb)
