DATI TECNICI
TECHNICAL DATA
DATI TECNICI Italiano TECHNICAL DATA English
NEOS
NEOS10P NEOS12P NEOS15P
System type 2-way vented enclosure 2-way vented enclosure 2-way vented enclosure
Nominal impedance 8 ohm 8 ohm 8 ohm
Input power rating continuous 250 W 350 W 400 W
Input power rating peak 500 W 700 W 800 W
Frequency response 70 Hz - 20 kHz 55 Hz - 20 kHz 50 Hz - 20 kHz
Sensitivity 97 dB @ 1 W/1 m 99 dB @ 1 W/1 m 99 dB @ 1 W/1 m
Low frequency device 10'' neodymium woofer - 2" VC 12'' neodymium woofer - 2.5" VC 15'' neodymium woofer - 2.5" VC
High frequency device 1'' compression driver - titanium diaphragm 1'' compression driver - titanium diaphragm 1'' compression driver - titanium diaphragm
Crossover frequency 2500 Hz 2000 Hz 2000 Hz
Angular coverage 100°>80° H x 60° V with asymmetrical rot
a
100°>80° H x 60° V with asymmetrical rot
a
100°>80° H x 60° V with asymmetrical rot
a
Signal processing Proel DSO480 (Biamp mode) Proel DSO480 (Biamp mode) Proel DSO480 (Biamp mode)
Connectors 2 x Neutrik Speakon® NL4MP linked 2 x Neutrik Speakon® NL4MP linked 2 x Neutrik Speakon® NL4MP linked
Construction 15 and 18 mm birch plywood 15 and 18 mm birch plywood 15 and 18 mm birch plywood
Finishing Anti-scratch highly resistant blackpaint Anti-scratch highly resistant blackpaint Anti-scratch highly resistant blackpaint
Flying system 4 x M10 - top, bottom, rear 4 x M10 - top, bottom, rear 4 x M10 - top, bottom, rear
Trapezoidal taper 10° 10° 10°
Monitor taper 42° 42° 42°
Mounting pole 1 x bottom double angle flange, 0° or 7.5° 1 x bottom double angle flange, 0° or 7.5° 1 x bottom double angle flange, 0° or 7.5°
Dimensions (W x H x D) 355 x 520 x 310 mm 400 x 600 x 365 mm 465 x 688 x 430 mm
Weight 14 kg (30.9 lb) 16 kg (35.3 lb) 21 kg (46.3 lb)
Constant voltage transfomer
Optional 100 V
NEOS10TBI (black, with foam)
NEOS10TWI (white, with foam)
Optional 100 V
NEOS12TBI (black, with foam)
NEOS12TWI (white, with foam)
Optional 100 V
NEOS15TBI (black, with foam)
NEOS15TWI (white, with foam)
NEOS10A NEOS12A NEOS15A
System type 2-way digitally processed active enclosure 2-way digitally processed active enclosure 2-way digitally processed active enclosure
Amplifier continuous power
250 W + 100 W (limited) bi-amp 350 W + 100 W (limited) bi-amp 400 W + 100 W (limited) bi-amp
Max SPL
124 dB 127 dB 128 dB
Connectors
IN - LINK: XLR M - XLR F
MAIN LINK: PowerCon® (NAC3MPB)
MAIN: PowerCon® (NAC3MPA)
IN - LINK: XLR M - XLR F
MAIN LINK: PowerCon® (NAC3MPB)
MAIN: PowerCon® (NAC3MPA)
IN - LINK: XLR M - XLR F
MAIN LINK: PowerCon® (NAC3MPB)
MAIN: PowerCon® (NAC3MPA)
Controls Amp level (-18 dB), gnd lift, HPF 80 Hz Amp level (-18 dB), gnd lift, HPF 80 Hz Amp level (-18 dB), gnd lift, HPF 80 Hz
Cooling Natural convection Natural convection Natural convection
Crossover frequency 2500 Hz 2000 Hz 2000 Hz
Input Impedance LINE: 20 kohm balanced, 10 kohm unbalanc LINE: 20 kohm balanced, 10 kohm unbalanc LINE: 20 kohm balanced, 10 kohm unbalanc
Input Sensitivity LINE: +4 dBu / 1.25 V LINE: +4 dBu / 1.25 V LINE: +4 dBu / 1.25 V
Power Supply 230 VAC 50Hz or 117 VAC 60 Hz 230 VAC 50Hz or 117 VAC 60 Hz 230 VAC 50Hz or 117 VAC 60 Hz
Maximum Consumption 1340 VA 1340 VA 1340 VA
Rated Consumption (1/8 Pout) 370 VA 370 VA 370 VA
Signal Processing 24 bit / 48 kHz 24 bit / 48 kHz 24 bit / 48 kHz
Weight 16 kg (35.3 lb) 18 kg (39.7 lb) 23 kg (50.7 lb)
