PROEL NEOS SERIES User Manual

7
POWER AMPLIFIER
INPUT
LINK
INPUT INPUTINPUT
LINK
CAVI CONSIGLIATI - ESEMPI DI CONNESSIONE
SUGGESTED CABLES - CONNECTION EXAMPLES
SATELLITE
SUBWOOFER
INPUT
INPUT
SATELLITE
SUBWOOFER
HF AMPLIFIER
LF AMPLIFIER
LOUDSPEAKER PROCESSOR ASO25 or DSO480
from mixer
INPUT
INPUT
ACTIVE SYSTEM
OPTIMIZER
LIMITER
CH1 CH2
ON
ASO25
ESEMPI DI CONNESSIONE Italiano
CONNECTION EXAMPLES English
NEOS
MODELLI PASSIVI
PASSIVE MODELS
ESEMPIO 1 - STEREO RILANCIATA EXAMPLE 1 - STEREO LINKED
ESEMPIO 2 - STEREO SUB E SATELLITE EXAMPLE 2 - STEREO SUBWOOFER AND SATELLITE
CAVI CONSIGLIATI Italiano SUGGESTED CABLES English
1
2
3
Proelcode: HPC624
1)Bare copper 12 AWG = 80x0,25mm (4.00 mm
2
)
2)PVC ø 4.00mm
3)FLEXIBLE PVC 60shore ø 11.00 mm
1
2
3
Proelcode: HPC620
1)Bare copper 14 AWG = 48x0,25mm (2.50 mm
2
)
2)PVC ø 3.20mm
3)FLEXIBLE PVC 60shore ø 8.40 mm
