USB2CAN converter
To work with a Pronet network you need a USB2CAN converter that converts the USB data flow into the CAN bus. The USB2CAN
converter needs to be connected to a USB 2.0 full speed port.
USB2CAN Features:
ARM7 microcontroller inside
Galvanic isolation 500 V
Voltage supply via USB bus
USB 2.0 full speed
High productivity on 1Mbit CAN bus speed
Wide CAN bus baud rate range: 10-1000 Kbit/s
Compliant with CAN specifications 2.0A (11-bit ID) and 2.0B (29-bit ID)
Firmware upgrade via bootloader
Drivers for Windows 2000, Windows XP, Windows Vista,Windows 7
ToinstallcorrectlythesoftwaredriverfortheUSB2CANconvertersee"Installation"and"Drivers"paragraphsintheincludedoronline
ducumentation.
When you connect the converter to the USB port of the PC, the LED on the top lights RED: this mean that it is powered but the converter
is not working yet.
Thersttimeyougo"online",thePronetsoftwareapplicationstartstocontrolthenetworkviatheUSB2CANcontroller,sendingand
receiving datas from connected devices. If everything is OK the LED on the top of the converter lights GREEN indicating the activities
on the network.
If there is a problem with the software driver, with network bus or there is a problem on the converter the LED flashes red and/or green.
STATUS LED operation
RED/GREEN toggling PC USB driver isn't installed
RED steady converter is not working
GREEN steady converter is working
GREEN blinking slow there is a problem in the bus
GREEN blinking fast there is a problem in the bus
RED blinking slow there is a problem in the bus
RED and GREEN steady Service mode
