ASSEMBLY
Place all parts of the PROFORM
¨
975s in a cleared area and remove the packing materials. Do not dispose of
the packing materials until assembly is completed.
Assembly requires the included tools and your own adjustable wrench .
PART CHART
Use the part drawings below to identify the small parts used in assembly. The number in parenthesis below
each drawing refers to the key number of the part. The second number refers to the quantity used in assembly.
Note: Some small parts may have been pre-attached for shipping. If a part is not in the parts bag, check
to see if it has been pre-assembled.
M10 Split Washer (26)Ð3
M10 x 25mm Button Head Screw (25)Ð3
#8 x 5/8Ó Screw (22)Ð4
M6 x 38mm Button Head Bolt (18)Ð4
M6 x 16mm Hex Head Screw (24)Ð8
M10 Flat Washer (71)Ð4
M10 Nylon Locknut (72)Ð4
M6 Nylon Locknut (66)Ð4
M6 Split Washer (67)Ð4
M10 x 105mm Button Head Bolt (70)Ð4
M6 x 25mm Hex Head Screw (14)Ð4
M4 x 16mm Screw (34)Ñ1
