8. Insert the Pulse Wires (118) upward through
the Upright (3) as shown.
8
3
118
118
9
9. While a second person holds the Console
(5) near the Upright (3), connect the wires on
the Console to the Upper Wire Harness (48)
and to the Pulse Wires (118).
Insert the excess wire into the Upright (3) or
into the Console (5).
Tip: Avoid pinching the wires. Attach the
Console (5) to the Upright (3) with four M4 x
16mm Round Head Screws (101).
5
118
48
101
3
Avoid pinching
the wires
10. Attach the Upright Cap (4) to the Console
(5) with two M4 x 16mm Round Head
Screws (101).
10
5
4
101
To Next Page
