Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the
packing materials, Do not dispose of the packing materials until assembly is completed, tn addition to the
included allen wrenches, assembty requires a phillips screwdriver _ _, an adjustabJe
wrench __ , and a rubber mallet ,_............... i i "
•........ ] i
As you assemble the elliptical exerciser, use the drawings below to identify small parts, The number in parentheses
below each drawing is the key number of the part, from the PART LIST on page 21, The second number is the
quantity needed for assembly, Note: Some small parts may have been pre-assembled. If a part is not in the
parts bag, check to see if it has been pre=assembled, tf a part is missing, call toll=free 1=888=533=1333.
M8 Split
Washer (100)-4
/// .- _'x i
.' / \
_'X \\" / //
..... /
M10 Split
Washer (70)-2
Wave Washer M8 Large M8 Nylon M10 Nylon
(95)-2 Washer (53)-10 Locknut (46)-8 Locknut (29)-4
M4 x 16mm
Screw (66)-4
M8 x 25mm Patch
Screw (22)-2
M8 x 45mm Button
Bolt (50)-4
M8 x 50mm Button
Screw (89)-4
M4 x 19mm
Screw (74)-2
M8 x 65mm Button
Screw (99)-4
M10 x 52mm Bolt Set (27)-2
\
To Next Page
