17
5.2.3 Alphabet Explanation
CHARACTER
ALPHABET
A B C D E F G H I J K L M N O P Q R S T U V X Y
Figure 23 Switch ON /OFF Pump Figure 24 Switch ON /OFF all of the DC Loads
Table 9 Switch Explanation
5.2.2 Switch Explanation
SWITCH FUNCTION DESCRIPTION
SILENT & Stop the fan ventilation in order to reduce the noise
Refer to 2.11
Press ‘Silent/Esc’ button until
shows on the
screen, then press ‘Light/Enter’.
PUMP & To switch on/off pump
Pump on:
Pump off:
The detailed steps are shown as below Figure 23
LOAD & To switch off all the loads connected on DC charger The function is the same as load switch in PM4SW10.
The detailed steps are shown as below Figure 24
LIGHT To adjust the brightness and switch off the
backlight of he monitor
Total three levels of brightness
LIGHT For
Setting
To set clock, battery battery tank quantity etc Hold down the ‘LIGHT’ button until the Date zone
(Table 16) shows the setting code. It means the unit
enters the setting mode. For the full details of setting
codes, please refer to Chapter 6.2.1
PUMP PUMP LOAD LOAD
Load
Load
Load
OFF
OFF
ON
Load
ON
Table 10 Alphabet code
