Page #10 background image
10
Battery voltage parameters
(Parameters is in 12V system at 25
o
C , please use X 2 in 24V.)
Control voltage parameters
Battery charging setting Gel Sealed Flooded User
Over voltage disconnect voltage 16.0V 16.0V 16.0V 9–17V
Charging limit voltage 15.0V 15.0V 15.0V 9–17V
Over voltage reconnect voltage 15.0V 15.0V 15.0V 9–17V
Equalize charging voltage 14.6V 14.8V 9–17V
Boost charging voltage 14.2V 14.4V 14.6V 9–17V
Float charging voltage 13.8V 13.8V 13.8V 9–17V
Boost reconnect charging voltage 13.2V 13.2V 13.2V 9–17V
Low voltage reconnect voltage 12.6V 12.6V 12.6V 9–17V
Under voltage warning
12.2V 12.2V 12.2V 9–17V
reconnect voltage
Under voltage
12.0V 12.0V 12.0V 9–17V
warning voltage
Low voltage disconnect voltage 11.1V 11.1V 11.1V 9–17V
Discharging limit voltage 10.6V 10.6V 10.6V 9–17V
Equalize duration 2 hrs. 2 hrs. 0–3 hrs.
Boost duration 2 hrs. 2 hrs. 2 hrs. 0–3 hrs.
Note: Battery voltage setting please in strict accordance with:
1. Over Voltage Disconnect Voltage > Charging Limit Voltage Equalize Charging Voltage
Boost Charging Voltage Float Charging Voltage > Boost Reconnect Charging
Voltage;
2. Over Voltage Disconnect Voltage > Over Voltage Reconnect Voltage;
3. Low Voltage Reconnect Voltage > Low Voltage Disconnect Voltage Discharging Limit
Voltage;
4. Under Voltage Warning Reconnect Voltage > Under Voltage Warning Voltage
Discharging Limit Voltage;
5. Boost Reconnect Charging Voltage > Low Voltage Disconnect Voltage.
