11
Load setting
The page of load setting could be used to set the four load working modes of the
connection solar controller (Manual, Light on/off, Light on+timer, Time control).
1. Manual control
Mode Introductions
ON Load is on all the time if battery capacity is enough and no abnormal
conditions happen.
OFF Load is OFF all the time.
2. Light ON/OFF
Light ON voltage When input voltage of solar module is lower than light ON voltage,
(Night threshold) it automatically turns ON load output if battery capacity is enough and no
abnormal conditions happen.
Light OFF voltage When input voltage of solar module is higher than light OFF voltage,
(Day threshold) it automatically turns off load output.
Delay time The confirmation time for Light signal. During the period, if light signal
voltage continues matching Light ON/OFF voltage, it will carry out
corresponding actions (The time adjustment range: 0–99mins.)
Manual Control
Light on/off
Time Control
Light on+Timer
Manual Control
Manual Control
Manual Control
Light on/off
Light on/off
Light on/off
Time Control
Time Control
Time Control
Light on+Timer
Light on+Timer
Light on+Timer
Manual Control
Default: ON/OFF
Light: on/off
on: 5.0VDeT: 10M
off: 4.0VDeT: 10M
Light: on+Timer
on: 5.0VDeT: 10M
off: 4.0VDeT: 10M
NightTime: XXH:XXM
Light: on+Timer
On Time 1: XXH:XXM
On Time 2: XXH:XXM
Time Control
Time 1
On Time H:M:S
Off Time H:M:S
Time Control
Time 2
On Time H:M:S
Off Time H:M:S
