Load current icon
The load current icon is displayed if there is discharge current.
Load status icon
Load ON, Load OFF.
OPERATION
Buttons
Esc OK
The buttons are respectively (from left to right) “ESC”, “Left”, “Up”, “Down”,
“Right” and “OK “buttons, the operation is described in the schematic operation
diagram below:
Schematic operation diagram
The default entry page is the browse mode. Pressing
button and inputting the
correct password to enter the modification mode; and buttons could be used to
move the cursor, and buttons could be used to modify the parameter values when
the cursor is located at the current place; and buttons could be finally used to
respectively confirm and cancel the modification of the control parameters.
Main menu
“Up” and “Down” buttons are respectively used to move the cursor to select the menu
items, “OK” and “ESC” buttons are respectively used to enter or exit the corresponding
pages of the menu items.
1. Monitoring
2. Device Info.
3. Test operation
4. Control Para.
5. Load set
6. Device Para.
7. Device PSW
8. Charge Mode
9. Factory Reset
10. Failure Info.
11. Meter Para.
OK OK
Esc Esc
Main menu
Browse
subpages
Edit
parameters
