English - 29 -
Connect Peripheral Equipment
High Definition
Your LCD Television is capable of displaying High Defi-
nition pictures from devices such as a High Definition
Satellite Receiver or DVD Player. These devices must
be connected via the HDMI socket or Component
Socket. These sockets can accept either 720p or
1080i signals.
Note: When it is desired to watch HDMI source with a
DVI to HDMI cable; in order to enable audio, Audio
Input (which is located at the left side of the antenna
input) is to be used to get DVI device’s audio signals.
Via The Scart
The TV has 2 Scart sockets. If you want to connect
peripherals (e.g. video, decoder, etc.) which have
Scart sockets to the TV, you can use SCART socket
of the TV.
Note: If an external device is connected via the Scart
sockets, the TV will automatically switch to AV mode.
If both sockets are employed at the sime time, SCART
1 becomes the preferential.
Via Aerial Input
If the device you want to connect does not have a
Scart socket, you should connect it to the Aerial input
of the TV.
Decoder
If you are subscribed to cable TV offers, the
organisation will supply you a corresponding decoder
unit to allow the programmes to be unscrambled.
For further information consult your dealer.
Connect a decoder with an aerial socket to
the TV
• Connect the aerial cable.
Connect a decoder without an aerial socket
to the TV
• Connect the decoder to the EXTERNAL socket of
TV with a RCA cable. Through the SCART/RCA
socket of the decoder, you may attain a better dis-
play resolution.
TV And Video Recorder
• Connect the aerial cables.
Better picture quality can be obtained if you also con-
nect a Scart cable to
SCART sockets.
Playback NTSC
• Connect NTSC VCR player to a Scart socket of the
TV.
Then, press the “
AV
” button to select EXT1 or EXT2.
Copy Facility
Source selection for VCR recording.
• Select Feature menu.
• Select
SCART 2 Out by pressing “ ” or “ ” button.
• For copying the picture that comes from the tuner,
select SCART 1.
Camera And Camcorder
To Connect To AV Input
Connect your camera or camcorder to AV input of the
TV.
• Connect your equipment to the TV via
VIDEO (yel-
low),
AUDIO R (red) and AUDIO L (white) inputs.
You must connect the jacks into the input with the
same colour.
To Connect To S-Video Input
Connect your camera or camcorder S-Video input of
the TV.
• Connect your equipment to the TV via S-Video input
and audio inputs of AV inputs by using S-Video
cables.
Connect The Decoder To The Video
Recorder
Some video recorders have a special Scart socket
for decoder.
• Connect a Scart cable to the Scart socket of your
decoder and to the special Scart socket of your
video recorder. Refer to the booklet of your video
recorder.
Connecting Headphones
Use the stereo headphone socket of the TV, to con-
nect headphones.
Note: If you want to connect more equipment to your
TV, consult your dealer.
)
Connecting Subwoofer
Use Subwoofer Out socket to connect an external,
active subwoofer to the set to give a much deeper bass
effect.
Connecting External Equipment
To connect audio amplifiers or home theatre systems
to your TV, use the Audio Line Outs of the TV.
