ProMinent
®
4
Steuerelemente und Tastenfunktionen
1 LCD-Anzeige
2 Hublängeneinstellknopf
3 AUF-Taste
4 P-Taste
5 AB-Taste
6 STOP/START-Taste
7 i-Taste
8 LED-Anzeige rot, für Störmeldungen
9 LED-Anzeige gelb, für Warnmeldungen
10 LED-Anzeige grün, für Betriebsanzeige
Steuerelemente und Tastenfunktionen
11 Buchse Dosierüberwachung
12 Buchse externe Ansteuerung
13 Buchse Niveauschalter
14 Buchse Membranbruchmelder
15 Buchse CANopen-Bus
16 LED-Anzeige rot-grün,
für Bus-Status-Meldungen
(CANopen-LED)
17 LED-Anzeige rot-grün,
für Geräte-Status-Meldungen
(device-LED)
Abb. 1: Steuerelemente
10
9
7
8
6
1
2
3
4
5
12 11 13 14
17
16
15
