ProMinent
®
36
Annexe
2A30h 0 volume count U32 in ml since last reset ro
2A31h 0 stroke count U16 strokes since last reset ro
2A33h 0 remaining strokes U16 Remaining stroke nr.
(in batch mode) ro
2A35h
0 number of entries U8 ro
1 flowcontrol U8 flowcontrol enable/disable wo
2 charge memory U8 charge memory enable/disable wo
3 clear charge counter U8 1 = clear counter wo
3FACh for debugging only
0 number of entries U8 ro
1 errors U16 internal error states ro
2 warnings U16 internal warning states ro
3 internal address U8 internal gateway addressro
3FBBh Prominent IdentCode
0 number of entries U8 8 ro
1 IdentCode string[4] IdentCode 29 - 32 ro
2 IdentCode string[4] IdentCode 25 - 28 ro
3 IdentCode string[4] IdentCode 21 - 24 ro
4 IdentCode string[4] IdentCode 17 - 20 ro
5 IdentCode string[4] IdentCode 13 - 16 ro
6 IdentCode string[4] IdentCode 9 - 12 ro
7 IdentCode string[4] IdentCode 5 - 8 ro
8 IdentCode string[4] IdentCode 1 - 4 ro
3FBCh Prominent SerialNumber
0 number of entries U8 8 ro
1 SerialNumber string[4] SerialNumber 29 - 32 ro
2 SerialNumber string[4] SerialNumber 25 - 28 ro
3 SerialNumber string[4] SerialNumber 21 - 24 ro
4 SerialNumber string[4] SerialNumber 17 - 20 ro
5 SerialNumber string[4] SerialNumber 13 - 16 ro
6 SerialNumber string[4] SerialNumber 9 - 12 ro
7 SerialNumber string[4] SerialNumber 5 - 8 ro
8 SerialNumber string[4] SerialNumber 1 - 4 ro
3FBDh user pump name
0 number of entries U8 8 ro
1 name string[4] name character 29 - 32 ro
2 name string[4] name character 25 - 28 ro
3 name string[4] name character 21 - 24 ro
4 name string[4] name character 17 - 20 ro
5 name string[4] name character 13 - 16 ro
6 name string[4] name character 9 - 12 ro
7 name string[4] name character 5 - 8 ro
8 name string[4] name character 1 - 4 ro
