ProMinent
®
Page 22
Ter minal box
(only in systems
with conventional ballast)
Mounting panel
(only in systems
with conventional ballast)
UV sensor
Bleed valve
Assembly support
Safety shield
Bleed valve
Motor support
Support stirrup
Wiper
Support panel
Base
Spindle nut
Temperature sensor
Plastic screw
Locking nut
UV sensor
O-ring
Limit switch
Assembly and Installation
