ProMinent
®
Page 43
Spare parts list
No. Description Part number Replacement Pieces
Interval
101 Powerline 2/3 kW radiator 1009385 approx. 8.000 h 1
101 Powerline 4 kW radiator 1009386 approx. 8.000 h 1
101 Powerline 6 kW radiator 1009387 approx. 8.000 h 1
101 Powerline 8 kW, 10 kW radiator 1009388 approx. 8.000 h 1
102 Radiator protection tube 863 mm long, 1*2/3ML 1009214 as required 1
102 Radiator protection tube 1213 mm long, 1009215 as required 1
1*4ML, 1*6ML
102 Radiator protection tube 1513 mm long, 1009216 as required 1
1*8ML, 1*10ML
111 Spacer (glass tube) 1009642 as required 1
130 UVC sensor M 1.4539 silicone free 1025685 as required 1
141 O-ring 234.32 – 5.33, f. flange 1*2/3ML/22/DN100 1009036 after 1
141 O-ring 291.47 – 6.99, f. flange 1*4ML/27/DN200 1009037 every 1
141 O-ring 342.27 – 6.99, f. flange 1*6ML, 1*8ML, 1009038 open the 1
1*10ML/32/DN250 radiation
141 O-ring 417.96 – 6.99 , f. flange 1009039 chamber 1
1 *10M L/40/DN300
150 O-ring 35 - 4, radiator protection tube seal 1027553 as required 2
153 O-ring 22 -3, probe seal 1002175 as required 1
301 mechanism 1009400 as required 1
307 Protective cover 1010385 as required 1
308 In-line rapid coupling 1009187 as required 1
313 Spindle 907 lg., 1*2/3ML 1010041 4 years 1
313 Spindle 1247 lg., 1*4ML, 1*6ML 1010042 4 years 1
313 Spindle 1547 lg., 1*8ML, 1*10ML 1010096 4 years 1
314 O-ring 40.00-2.50 EPDM/P 1005850 as required 1
316 X-ring seal drive spindle 1010384 1-2 years 1
320 Ball bearing complete with receptacle 1010040 4 years 1
325 Friction bearing compl. 1009953 4 years 1
330 Drive nut 1010116 2 years 1
570 Wiper motor 1009399 as required 1
880 Filter mat SK3172/100, control cabinet ventilation 791038 1/2 - 1 year 2
900 Wiper compl. 1009976 2 years 1
901 Magnet 1009654 as required 1
904 Stop position switch 1009357 as required 2
Spanner for d68-75 with pivot d6 1009515 as required 1
Sealing cement Neofermit 553004 as required 1
Tap grease OKS 477 791681 as required 1
