n ixStart_Stop
n irSetpoint0_100
n ixFault_Lock
n oxError
n oxErrorProfibus
The pumps starts, if:
ixStartStop = 1 & (ixFault_Lock = 0 or (ixFault_Lock = 1 & oxError = 0 &
oxErrorProfibus = 0)
with metering speed (strokes / h)
Maximum frequency * irSetpoint0_100 / 100
The pump does not start up, if:
ixStartStop = 0
3.3.1.2
Mode type batch
In
“Charge” mode the following signals are relevant:
n ixStart_Stop
n ixStartBatch_Or_Contact
n ixBatchContactMemory
n irSetpoint0_100
n idStrokesInBatch
n ixFault_Lock
n oxError
n oxErrorProfibus
n odActualStrokesInBatch
n odRemainStrokesInBatch
Without memory function: ixBatchContactMemory = 0
With the input
“ixStart_Stop” the pump can be switched off at any time.
Recommendation for operation: “Set ixStart_Stop” on 1 and only on 0 if
needed.
The input
“irSetpoint0_100” specifies the metering speed.
Locking mechanism = manual mode
“ixStartStop” = 1 & ( “ixFault_Lock” = 0 or ( “ixFault_Lock” = 1 & “oxError”
= 0 & “oxErrorProfibus” = 0)
Metering speed (strokes / h) =
Maximum frequency *
“irSetpoint0_100” / 100
The pump does not start up, if:
“ixStartStop” = 0
The pumps starts, at:
Positive flank on input “ixStartBatch_Or_Contact” .
Remaining strokes will be set to the value “idStrokesInBatch”
( “odRemainStrokesInBatch” = “idStrokesInBatch” ). The metering pump
runs until the remaining strokes counter is on 0.
A renewed flank on “ixStartBatch_Or_Contact” resets the value of the
remaining strokes to “idStrokesInBatch” . If the flank occurs during the
batch, the value will be limited to only idStrokesInBatch.
With memory function: ixBatchContactMemory = 1
Same as “Without memory function: ixBatchContactMemory = 0, but ...
The pumps starts, at:
Function blocks for gamma/L and Sigmas
35
