4 Overview of equipment and control elements
P_SI_0190_SW
1
2
5
6
7
4
3
Fig. 2: Overview of Sigma X - S1Cb equipment
1 HMI control unit
2 Frequency converter
3 Drive unit
4 Stroke length adjustment wheel
5 Drive motor
6 Liquid end
7 Diaphragm rupture sensor
1
2
P_SI_0088_SW_2
Fig. 3: Sigma control elements
1 Bleed valve (optional)
2 Diaphragm rupture sensor (visual)
Overview of equipment
Control elements
Overview of equipment and control elements
13
