19 Liquid ends for Sigma/ 1
P_SI_0024
1
5
4
5
6
2
3
Fig. 44: Liquid end for Sigma/ 1 050 and 065 PVT
Pos. Description
1 Spring *
2 Ball
3 Ball seat
4 Diaphragm rupture sensor, optical *
5 Valve
6 Multi-layer diaphragm
The items listed are included in the spare parts kit. * Special accessories
(not included in the spare parts kit). Technical changes reserved.
Liquid end for Sigma/ 1 050 and 065 PVT
Liquid ends for Sigma/ 1
94
