Page #32 background imageLoading...
Page #32 background image
WARNING!
Danger of electric shock
A mains voltage may exist inside the motor or electrical
ancillaries.
If the housing of the motor or electrical ancillaries
has been damaged, you must disconnect it from the
mains immediately. Only return the pump to service
after an authorised repair.
CAUTION!
Use ProMinent cables to avoid unnecessary problems.
What requires electrical installation?
n Level switch
n Diaphragm rupture sensor, electrical (optional)
n Metering monitor (optional)
n Relay (optional)
n External control
n mA output (optional)
n Bus connector (optional)
n Pump, power supply
7.2.1 Control connectors
CAUTION!
Incoming signals can remain without effect
If the universal control wire, the external/pacing cable or
the level monitoring cable is shortened below 1.20 m,
the pump does not detect that it is connected. Conse‐
quently a warning message (for example) can be sup‐
pressed.
Do not shorten this cable below 1.20 m.
Connect the plugs of the level switch, diaphragm rupture sensor and
metering monitor to the corresponding sockets on the front side of the con‐
trol. If in doubt - refer to the "Overview of equipment and control elements”
chapter.
CAUTION!
Danger resulting from unnoticed diaphragm rupture
If the pump has been ordered with an electric diaphragm
rupture sensor, it must also be electrically installed.
Electrically connect the enclosed diaphragm rupture
sensor.
What requires electrical installation?
Level switch, diaphragm rupture sensor
(option) and metering monitor (option)
Installation
32
